Product Description:
Vstar Security is a Premiere Manufacturer of Burglar Alarm Systems in Shenzhen, China. We manufacture
complete range of Burglar Alarm Systems. We offer a wide range of Burglar Alarms with different features in a flexible cost differences.
VStar Security Provides Security Solutions for Home Security, Video Surveillance, Access Control, Fire Alarm and Automation. Vstar Security provide professional GSM alarm system, Wireless burglar alarm, China House security system, Security Camera, Surveillance Cameras, CCTV Cameras, Weatherproof IR Cameras, Standalone DVR, Acess Control System, Door Control System, Digital Alarm Receiver, ADMECO Contacct ID Alarm Receiver, DSC Alarm Receiver, Central Monitoring Station for world-wide customer.
Main Features:
- MJPEG compression; support CIF;
- 4 Channel Video Input & 1 Channel Video Output;
- USB connection to PC ;
- Professional software for video playback and storage;
- File format: AVI and MYS;
- NTSC/PAL Selectable;
- Video lost alarm;
- Support HDD>500G ;
- Schedule/Motion detection recording;
- Remote power supply for 4 channel cameras;
- Selectable English & Chinese;
- Applied in small surveillance area, such as House, Small Super Market, Gas Station, Villa, etc.
Technical Parameters:
Model SKY-J104
Compression
(Single Channel) MJPEG
Storage space: 12K-20K/Frame
Video Input/ Output NTSC : 4 Channel BNC Input/1 Channel BNC Output
PAL : 4 Channel BNC Input/1 Channel BNC Output
Display Frame Rate NTSC : 120 FPS(4 x 30 FPS)
PAL : 100 FPS(4 x 25 FPS)
Record Frame Rate
(Full Screen Mode) NTSC : Max 7.5 FPS 163 x 138
PAL : Max 6.25 FPS 163 x 138
Record Mode Manual, Schedule, Motion Detection
Record Resolution NTSC : 320 x 112 640 x 224
PAL : 320 x 136 640 x 272
Playing Mode 1 Channel or 4 Channel
Searching Mode By Time/ By Date/ By Event
HDD >500G、Support SATA HDD
Remote Control Yes
Alarm Video Lost Alarm
USB Port USB2.0
Language Support Simplified Chinese, English
7 Inch Hidden TFT Monitor No
Cameras's remote power supply No
Power Supply 12V/ 3A DC
Working Temperature -10℃ - +50℃
Working Humidity 10% - 90%
G.w/ n.w 3.5kg
Meas (L x W x H) 330 x 230 x 60mm
