Product Description:
Dingbo Power diesel generator set powered by Yuchai engine can be 20kw to 3000kw, which is characterized
by energy-saving and environment-friendly, high reliability, strong loading capability and good maintainability.
350KW 437.5KVA Diesel Generator Set Specifications
Genset model DB-350GF
Prime power 350 kW 437.5 kVA
Standby power 385 kW 481 kVA
Rated voltage(V) 400/230 (customizable)
Rated current(A) 630 A
Power factor 0.8
Frequency(Hz) 50
Speed(rpm) 1500
Phase: 3 phase 4 wire
Noise level: 105dB at 7m ( open type diesel genset)
75dB at 7m(silent type diesel genset)Engine Specifications
Manufacturer Yuchai
Model YC6MJ600-D30
Engine output-prime 401kW
Engine output-standby 441kW
Frequency: 50Hz
Speed: 1500rpm
Cylinders no. & Type: 6 cylinders, Inline, 4 stroke, diesel engine, water-cooled
Aspiration: Turbocharged&Intercooled
Bore*stroke 131*145mm
Displacement 11.73L
Compression Ratio 14:1
Governor Electronic speed governor
Starter motor voltage: 24V DC
Type Injection System: direct injection
Oil capacity(dry engine): 37L
Engine oil and fuel consumption ratio ≤0.1%
Cooling way Water Radiator & fan
Fuel consumption-standby power(100%) 109.3L/h
Fuel consumption-prime power(100%) 97.3L/h
Fuel consumption-prime power(75%) 74.0L/h
Fuel consumption-prime power(50%) 49.3L/h
