Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number acs750lca-050
BRAND Allegro MicroSystems [Allegro]
Packaging 5-ca
Date code 10+
PRICE Email us
Summary current sensor ICs, Single +5 V supply, 13 kHz bandwidth
Description as follow:
The ACS750LCA-050 family of current sensor ICs provides economical and precise solutions for current sensing in industrial, automotive, commercial, and communications systems. The device package allows for easy implementation by the customer. Typical applications include motor control, load detection and management, power supplies, and overcurrent fault protection.
Parametrics
Absolute maximum ratings: (1)Supply Voltage: 16 V; (2)Reverse Supply Voltage: –16 V; (3)Output Voltage:16 V; (4)Reverse Output Voltage: –0.1 V; (5)Maximum Basic Isolation Voltage: 353 VAC, 500 VDC, or Vpk V; (6)Maximum Rated Input Current: 100 A; (7)Output Current Source: 3 mA; (8)Output Current Sink: 10 mA; (9)Nominal Operating Ambient Temperature: Range L –40 to 150 ℃, Range S –20 to 85 ℃; (10)Maximum Junction: 165 ℃; (11)Storage Temperature: –65 to 170 ℃.
Features
Features: (1)Monolithic Hall IC for high reliability; (2)Single +5 V supply; (3)3 kVRMS isolation voltage between terminals 4/5 and pins 1/2/3 for up to 1 minute; (4)13 kHz bandwidth; (5)Automotive temperature range; (6)End-of-line factory-trimmed for gain and offset; (7)Ultra-low power loss: 130 μΩ internal conductor resistance; (8)Ratiometric output from supply voltage; (9)Extremely stable output offset voltage; (10)Small package size, with easy mounting capability; (11)Output proportional to AC and DC currents.
Diagrams
