Api Forged Steel Swing Check Valve

Posted at: Offers to Sell and Export | Posted on: Tuesday 26 July 2011 11:56 am | Poster last visit: Thursday 1 September 2011 |

Product Category: Main » Distribution and Conditioning Systems and Equipment and Components » Fluid and gas distribution » Valves » Swing check valves » Api Forged Steel Swing Check Valve


Product Photo:

api forged steel swing check valve

Similar Products Catalog:
Products Photos Catalog Api Forged Steel Swing Photos Catalog

Product Description:

)Forged swing check valve

2)Design ANSI B16.34/API602


3)Test API 598

4)API certificate

5)Socket welded

end ANSI B16.11

API forged steel swing check valve

Size 1/2 to 2

Design Standard ANSI B16.34/API602

Test standard API 598

Socket welded end ANSI B16.11

Screwed end ANSI B1.20

Rating Class 800 1500 2500

Body A105 F5 F11 F22 F304 F304L F316 F316L

Cover A105 F5 F11 F22 F304 F304L F316 F316L

Nameplate Aluminum

Disc F6 316

Seat ring F6-HFS, 316-HFS

Retaining nut 2H, 2HM

Hinge A743-CA40 SS316

Hinge pin SS410 SS316

Supporter SS304 SS316

Gasket Graphite +304/316

Trims API #1(F6/F6), #5(HF/HF), 304, 316, Monel, NACE standard

Bonnet Welded Bonnet

End connection SW, NPT
