Product Description:
1.Simple introduction of activated charcoal briquette machine :
Zhongzhou series Briquette machine,
mainly used to suppress difficult molding powder materials, characterized by forming pressure, the host rpm adjustable, with a spiral Feeding Device. Briquette Pressing Machine can be used to suppress coal, iron, coke, aluminum powder, iron, iron oxide skin, toner, toner, slag, gypsum, tailings, sludge, kaolin, activated carbon, coke powder and other end, Powder, waste, waste residues, are widely used in refractory, power plants, metallurgy, chemical, energy, transportation, heating, etc., produced by the compression molding machine after the briquette materials, energy saving, easy to transport, increase of wastes Utilization, with good economic and social benefits .
2.Advantage of activated charcoal briquette machine:
1. High profit and low cost in raw material
2. Increase the calorific value per unit volume after briquetting
3. Energy saving, friendly-environment, Low-consumption
4. No chemical additives, no smell, no smoke
5. Easy to transport and store as densities product
6. High briquetting ratio, high pressure coal briquetting machine
3.Raw materials of activated charcoal briquette machine:
(1).Coal powder/coal fine/coal dust
(2).Charcoal powder/charcoal fine/charcoal dust
(3).Gypsum/Desulfurization Gypsum/quicklime/slaked lime/
(4).Activated carbon/carbon black
(5).All kinds of metal powder
(6).Iron oxide/aluminum oxide/clay
(7).Some other type powder.
4.Working principle of activated charcoal briquette machine:
This series of briquette making machine will pass the power on to the two pressure roller through the reducer. The two sides and roll rotation, in both the rotating roll. Natural materials to enter the ball roll mode, with the roll rotation, material pressure on a small become larger. When the material to the two rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous pressure in the role of line, the materials become a finished product from the powder ball.
5.Product Parameters:
Model:ZZXM-30
Power: 90kw
Capacity:30t/h 200thousand t/year
Overall size: 2965x2450x1980mm
Weight: 22.8t
Roller width/diameter: 500mm/850mm
Total pressure: 70t
rotary speed of main spindle:10r/min
line pressure of roll face:1
pressure stype: Interchangeable sype of hydraulic and mechanical
Roller materails: 65Mn 9Cr2Mo wear-resistant alloy
Heat treatment: 52~58°
Structural form: Four rollers double pressure
Ball shape: round, pillow-shaped, oblate, oval-shaped, diamond
Ball size:30~60mm
6.Our services:
(1)Pre-sale services:
According to your special needs, design and manufacture products for you, provide you with project design, process design, purchase program suitable for your machines and equipment.
(2)Sale of services:
Assist you to complete acceptance of the equipment, and the construction program and detailed process.
(3)After sale service:
Our factory sent technicians to teach how to install the equipment, commissioning and training of operators.
Any question pls contact me. It is our goal to offer the best service to you.
