Product Description:
* Full Screen Display in mode of Monitoring & Recording. No full screen in PlayBack.(from 10th 08,
2011).(Instructions: 1.Firstly Enter "DVI" mode, 2. Long Press "Menu" to make it display full screen. 3. Enter "HDMI" mode, 4. Long Press "Menu" to make it display full screen.)
*No Blue Screen and No delay when camera switches from Monitoring mode to Recording.(from 10th 08, 2011).(Instructions: 1.Firstly Enter "DVI" mode, 2. Enter "HDMI" mode, 3.Then Please start your camera Recording, No blue screen, No delay between switch.)
* 1 Earphone jack in the front panel in addition to a built-in speaker.
* Fixed battery plate w/ good lock system to lock SONY F550/F970
* White/Black color function
HD1 is Compatible w/ following batteries(Sony F970, F550, F570, F770, F750), We have Optional SONY F970 & F550:
Better have 2 units Battery because F970 needs 12 hours to be FULLY recharged, F550 needs 6 hours.
Display Screen
Panel Size
7" TFT LCD monitor(No Touchscreen)
Type a-Si TFT active matrix
LED Backlight
yes
Aspect Ratio
16:9
Display Ratio
16:9 or 4:3 adjustable
Image Flip
Vertical flip and Horizontal flip
Resolution
800×480
Brightness
400cd/㎡
Contrast
500:1
Viewing Angle
140°/ 110°(h/v)
Others
OSD Languages
10 languages: English, Chinese, Francais, Japanese, Italiano, Deutsch, Espanol, Pycc, Korean, Chinese traditional
Input Voltage
dc 7v - 24v
Current
650mA (1.2A when charging)
Standby Current
≤50mA
Power Consumption
≤8w
Input Resistance
75Ω
Input Frequency
H/30-60KHz, V/60-75Hz
Audio Output
≤1w
Speaker
×1(front)
