Corrugated Roll Forming Machine

Posted at: Offers to Sell and Export | Posted on: Wednesday 20 July 2016 8:34 am | Poster last visit: Monday 13 November 2017 |

Product Category: Main » Industrial Production and Manufacturing Services » Machining and processing services » Forming services » Roll forming services » Corrugated Roll Forming Machine


Product Photo:

corrugated roll forming machine

Similar Products Catalog:
Products Photos Catalog Corrugated Roll Photos Catalog

Product Description:

Item Roofing Corrugated Sheet Roll Forming Machine

Coil Material Thickness 0.3-0.8mm


Coil

width Custom-made, 1000mm or 1200mm or 1250mm

Yield Strength 250-350 Mpa

Material PPGI, Color Steel, GI.

Decoiler / Uncoiler Decoiler Type Manual or Hydraulic or Auto Type

Coil Width Max. 1250mm

I.D 508-610mm

O.D Max. 1500mm

Corrugated Sheet Roll Forming Machine Forming Stations 16 Stations ( Depend on Profiles )

Roller material 45# steel, surface coated with 0.05mm hard chrome

Diameter of shaft 76mm

Shaft material High grade 45# steel

Drive type Chain transmission

Forming speed 0-15m/min

Main power 5.5KW

Cutting Cutting type Hydraulic cutting

Cutting Die Material Cr12Mov steel, HRC58-62

Cutting power 3KW

CuttingTolerance 10m+/-1.5mm

Encoder OMRON Brand
