Product Description:
Cylindrical roller rotor bearing N18/1000mp5 for wire cable tubular stranding machine
The single row
cylindrical roller bearing N18/1000MP5 use for high speed tubular stranding machine for steel, copper and aluminum stranding.It including the outer ring, inner ring and cage with roller. The tubular stranding machine rigid rotor running supported by bearing at both ends.n18/1000 encircled bearing for higher speeds and more stability of the machine.
The size 1000x1220x100mm, inner diameter:1000mm, outer diameter :1220mm, height 100mm, with high precision grade P5 that can meet high speed rotation tubular stranding machine. Because of the bearing size, the inner ring and outer ring will drill hole for mounting hole when the customer fixed the bearing in the Tubular Strander machine.
Bearing code N18/1000MP5, n18.1000m
Bearing size 1000*1220*100mm
Bearing outer dia 1220mm
Bearing inner dia 100mm
Bearing height 100mm
structure Single row cylindrical roller
Rolling Roller
Ring material GCr15SiMn
Roller material GCr15
Cage material Brass
Precision grade P5 P6 Available
