Product Description:
DHT endless chain motor hoist is a kind of lifting equipment, It has widely used in mining and manufacturing
enterprises, stores and warehouses, medicine and healthy services and catering trade. It can be fixed on a steel beam, curved track and fixed point for carrying anything heavy and also on cantilever crane guide for carrying work piece and machine tools.
DHT electric hoist Parameters:
Model DHT1T DHT1.5T DHT2 DHT3 DHT5 DHT10 DHT20
Rated load T 1 1.5 2 3 5 10 20
Testing load T 1.5Gn 1.5Gn 1.5Gn 1.5Gn 1.25Gn 1.25Gn 1.25Gn
Motor power kw 0.3 0.3 0.3 0.3 0.75 0.75 0.75
Electric voltage V 380V 50HZ
Lifting speed m/min 0.9 0.9 0.45 0.45 0.46 0.23 0.23
Min distance between hooks mm 270 350 380 470 600 700 1000
Standard lifting height m 2.5 2.5 2.5 3 3 3 3
Round steel dia. of load chain mm 6 8 6 8 10 10 10
Load chain 1 1 2 2 2 4 8
N.W. kg 26 32 30 37 54 88 195
G.W. kg 28 34 32 42 66 102 235
Packing size cm 33*34*34 33*34*34 33*34*34 33*34*34 43*36*43 50*50*43 72*72*85
