Downpipe Roll Forming Machine

Posted at: Offers to Sell and Export | Posted on: Friday 15 July 2016 8:24 am | Poster last visit: Monday 31 October 2016 | | Europe | Australia

Product Category: Main » Industrial Production and Manufacturing Services » Machining and processing services » Forming services » Roll forming services » Downpipe Roll Forming Machine


Product Photo:

downpipe roll forming machine

Similar Products Catalog:
Products Photos Catalog Downpipe Roll Forming Photos Catalog

Product Description:

Main Specification:

 Main motor power: 7.5Kw


 Number of roll stand: About 20 stands

Forming

speed: 6-12m/min

 Voltage: 380 V, 3 Phase 50Hz ( or depend on customer’s requirement )

 Dimension of machine: About 12000mm*1100mm*1200mm

 Machine wight: about 12 Ton

 Material of Axis: High grade 45# steel

 Diameter of Axis: φ75mm

 Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.

 Materical of Machine Frame: A3 Steel, thickness 18mm

 Electrical Control: PLC Frequency Control System with touch screen

 PLC: PANASONIC Brand

 Encoder: OMRON Brand

 Transducer: PANASONIC Brand

Applications:

Rainwater downpipe, downspout, rainspout, water pipe, drainpipe
