Fod3120s Fairchild Semiconductor, Gate Drive Optocoupler, Sop
Posted at: Offers to Sell and Export | Posted on: Tuesday 25 September 2012 3:36 am | Poster last visit: Friday 26 July 2013 |
Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number fod3120s
BRAND Fairchild Semiconductor [Fairchild]
Packaging sop
Date code 11+
Price 0.1~1usd
Summary 2.5A Output Current, Gate Drive Optocoupler, SOP, 15V to 30V, Fast switching speed
Description as follow:
The FOD3120S is a 2.5A Output Current Gate Drive Optocoupler, capable of driving most 1200V/20A IGBT/MOSFET. It is ideally suited for fast switching driving of power IGBT and MOSFETs used in motor control inverter applications, and high performance power system. The FOD3120S consists of a gallium aluminum arsenide (AlGaAs) light emitting diode optically coupled to an integrated circuit with a high-speed driver for push-pull MOSFET output stage. The applications of the FOD3120S include: (1)Industrial inverter; (2)Uninterruptible power supply; (3)Induction heating; (4)Isolated IGBT/Power MOSFET gate drive.
Parametrics
FOD3120S absolute maximum ratings: (1)TSTG Storage Temperature: -55 to +125 ℃; (2)TOPR Operating Temperature: -40 to +100 ℃; (3)TJ Junction Temperature: -40 to +125 ℃; (4)TSOL Lead Wave Solder Temperature(refer to page 19 for reflow solder profile): 260 for 10sec ℃; (5)IF(AVG) Average Input Current: 25 mA; (6)VR Reverse Input Voltage: 5 V; (7)IO(PEAK)Peak Output Current: 3.0 A; (8)VCC-VEE Supply Voltage: 0 to 35 V; (9)VO(PEAK) Peak Output Voltage: 0 to VCC V.
Features
FOD3120S features: (1)High noise immunity characterized by 35kV/μs minimum common mode rejection; (2)2.5A peak output current driving capability for most 1200V/20A IGBT; (3)Use of P-channel MOSFETs at output stage enables output voltage swing close to the supply rail; (4)Wide supply voltage range from 15V to 30V; (5)Fast switching speed: 400ns max. propagation delay; 100ns max. pulse width distortion; (6)Under Voltage LockOut (UVLO) with hysteresis; (7)Extended industrial temperate range, -40℃ to 100℃ temperature range.
Diagrams
Company Contact:
Contact Name: John
Company Name: Excellent Integrated System Limited (eis Limited)
Email:
Tel: 00852-30777742
Fax: 00852-30777843
Street Address: Rm 906, Workingberg
Comm Bldg, 41-47 Marble Rd, Hong Kong
Member name: EISLIMITED
Country:
Hong Kong
Member Since: 29 August 2012
Total Leads: 537 EISLIMITED Import Export Business Leads
Business focus: Electronic Components, Active Component, Integrated Circuit, Semiconductor, Chips
Chat:
Verify: Safe Import Export Tips
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number fod3120s
BRAND Fairchild Semiconductor [Fairchild]
Packaging sop
Date code 11+
Price 0.1~1usd
Summary 2.5A Output Current, Gate Drive Optocoupler, SOP, 15V to 30V, Fast switching speed
Description as follow:
The FOD3120S is a 2.5A Output Current Gate Drive Optocoupler, capable of driving most 1200V/20A IGBT/MOSFET. It is ideally suited for fast switching driving of power IGBT and MOSFETs used in motor control inverter applications, and high performance power system. The FOD3120S consists of a gallium aluminum arsenide (AlGaAs) light emitting diode optically coupled to an integrated circuit with a high-speed driver for push-pull MOSFET output stage. The applications of the FOD3120S include: (1)Industrial inverter; (2)Uninterruptible power supply; (3)Induction heating; (4)Isolated IGBT/Power MOSFET gate drive.
Parametrics
FOD3120S absolute maximum ratings: (1)TSTG Storage Temperature: -55 to +125 ℃; (2)TOPR Operating Temperature: -40 to +100 ℃; (3)TJ Junction Temperature: -40 to +125 ℃; (4)TSOL Lead Wave Solder Temperature(refer to page 19 for reflow solder profile): 260 for 10sec ℃; (5)IF(AVG) Average Input Current: 25 mA; (6)VR Reverse Input Voltage: 5 V; (7)IO(PEAK)Peak Output Current: 3.0 A; (8)VCC-VEE Supply Voltage: 0 to 35 V; (9)VO(PEAK) Peak Output Voltage: 0 to VCC V.
Features
FOD3120S features: (1)High noise immunity characterized by 35kV/μs minimum common mode rejection; (2)2.5A peak output current driving capability for most 1200V/20A IGBT; (3)Use of P-channel MOSFETs at output stage enables output voltage swing close to the supply rail; (4)Wide supply voltage range from 15V to 30V; (5)Fast switching speed: 400ns max. propagation delay; 100ns max. pulse width distortion; (6)Under Voltage LockOut (UVLO) with hysteresis; (7)Extended industrial temperate range, -40℃ to 100℃ temperature range.
Diagrams
