Product Description:
This gas oven controller is applied to gas oven. The design consists of two GND electrodes which can
spark at the same time, two separated flame sensors and one solenoid valve. CSA certification is requested.The rated operating voltage is 120V and sparking rate is 60Hz.
Technical parameter
oven control board manufacturer:Guangdong Baiwei Electronic Co., Ltd.
Operating voltage range 110VAC-130VAC
Standby power consumption ≤1.5W
Operating current ≤1.5A
Valve pull-in voltage 3.0±0.2V
Sparking voltage 3.5±0.5V
Sparking current ≤150mA
Sparking rate ≥7Hz
HV output ≥12kV
Sparking pulse width ≥12us
Valve pull-in current ≥450mA
Valve hold current ≥5mA
Sparking time 5±2s
Valve pull-in time 1±0.5s
Sparking interval 12±2s
Maximum sparking time 3
Operating humidity range ≤95%
Operating temperature range -20℃~85℃
Storage temperature -40℃~70℃
Operating life ≥250000 cycles
Sparking gap ≥5mm
Energy output >1.0mJ
