Product Description:
TM -1000 Double Spindle Mixer
TM -1000 double spindle high speed mixer is efficient, energy saving,
discontinuing, and
speed controllable. Its 2 blade-spindles cross and counter rotate, and mix foamed concrete fast and
evenly. Disadvantages of double spindle mixer are a more and heavier; however, longer lifetime.
Foamed concrete consumes a larger amount of foam compare to cementitious material
(1-6 times). At the same time, its volume is larger than cementitious materials which mean more
foam and less mass, Cementitious material is heavier than foam concrete because of its
high-density. Foam concrete, on the other hand, is much lighter because of its low density. It is
also called light weight concrete. TM – 1000 runs 60 turns per minute.
Techniques:
1. Rack structure at the bottom; Easy discharging, foam concrete mass can be directly
discharged into storage.
2. Fast mixing, efficient, double spindles counter cross mixing. It only need s 30-60
seconds when mix with normal mortal.
3. Blades reach every part of the hopper, no waste, therefore, it saves cement.
4. Save energy—Mixer power is only 1/3 of normal double horizontal shaft mixer;
therefore, you are able to saving 50-70% electricity usage.
Key Parameters
Model TM 500-1000
Volume 750-1200 L
Engine Power 10.5-22 Kw
Engine Turn 1440 r/min
Reducer 1:23.34
Mixer speed 50 r/min
Charge 750-1200 L
Discharge 500-1000 L
Dimension 2700/1320/1650 mm
Output 10m3 per hou
