Product Description:
Habasit Flame retardant belts NSL-11ESBV
Technical Data
Thickness: 3.0 mm 0.12 in.
Mass of belt (belt
weight): 3.5 kg/m2 0.72 lbs./sq.ft
Nosebar Radius (minimum): NA mm NA in.
Pulley diameter (minimum): 40 mm 1.6 in.
Pulley diameter minimum with counter flection: 60 mm 2.4 in.
Tensile force for 1% elongation (k1% static) per unit of width (Habasit Standard SOP3-155 / EN ISO21181): 10 N/mm 57 lbs./in.
Tensile force for 1% elongation after relaxation (k1% relaxed) per unit of width (Habasit Standard SOP3-155 / EN ISO 21181): 6 N/mm 34 lbs./in.
Admissible tensile force per unit of width: 10 N/mm 57 lbs./in.
Operating temperature admissible (continuous): Min 0℃ Max 80 ℃ Min 32℉ Max 176 ℉
Coefficient of friction of driving pulley of steel: 0.15 [-] 0.15 [-]
Coefficient of friction of driving pulley with friction cover: 0.35 [-] 0.35 [-]
Coefficient of friction on slider bed of pickled steel sheet: 0.25 [-] 0.25 [-]
Coefficient of friction on slider bed of stainless steel sheet: 0.15 [-] 0.15 [-]
Seamless manufacturing width: 3000 mm 118 in.
On request other seamless manufacturing width: NA mm NA in.
At the same time, we still can offer the following items:
Habasit Flame retardant belts NSL-10ESBV
Habasit Flame retardant belts NNT-10ESBU
Habasit Flame retardant belts NMB-11ESBV
Habasit Flame retardant belts NHM-8ESBV
Habasit Flame retardant belts NHB-10ESBV
