Heavy-duty Precision Slewing Drives Used In Intelligent Manufacturing Workshops
Posted at: Offers to Sell and Export | Posted on: Sunday 23 October 2022 3:23 am | Poster last visit: Monday 23 September 2024 |
Product Category: Main
» Commercial and Military and Private Vehicles and their Accessories and Components
» Transportation components and systems
» Drivetrain systems
» Drive shafts
» Heavy-duty Precision Slewing Drives Used In Intelligent Manufacturing Workshops
Product Description:
Model: S-III-O-0655
Type: precision gear grinding slewing drive
Slewing drive gear ratio: 6.60
Rated
output torque: 25KN.M
Rotation center diameter: 655mm
Total height with adapter flange: 153mm
Gear backlash ≤0.15mm
S-III-O-0655 precision gear grinding slewing drive with three-stage gearboxes used for intelligent manufacturing workshop equipment, the customer uses ordinary motor to drive the slewing drive to rotate and stop when it reaches the specified position. The output speed of the slewing drive is required to be very low and the turntable should not have a large shaking after reaching the specified position.
According to the customer’s requirements, Unique Transmission recommended the 0655 slewing drive of the III series for the customer.In order to reduce the shaking of the rotary table, the slewing drive adopts zero clearance. The teeth are quenched and then ground to ensure that the slewing drive has a small tooth clearance, which ensures that the rotary table has only a small waggle after the motor is braked, which meets the customer’s requirements.
In the process of slewing drive selection and design, different slewing drives should be selected according to the specific working conditions and different precision and configuration. The ultimate goal is to provide customers with cost-effective, simple and reliable slewing drive products.
Company Contact:
Contact Name: Guoguo
Company Name: Unique Transmission Equipment（luoyang）co., Ltd
Email:
/
Tel: +86-379-64915181
Fax:
Street Address: No.22 Binhe Road,
New & High Tech Industry
Development Zone, Luoyang Area Of
China (henan) Pilot Free Trade Zone,
471000
Website: https://en.u-transmission.com
Member name: UniqueTransmission
Country:
China
Member Since: 16 June 2021
Total Leads: 196 UniqueTransmission Import Export Business Leads
Business focus: Slew Drive, Slewing Ring
Chat:
Verify: Safe Import Export Tips
Type: precision gear grinding slewing drive
Slewing drive gear ratio: 6.60
Rated
output torque: 25KN.M
Rotation center diameter: 655mm
Total height with adapter flange: 153mm
Gear backlash ≤0.15mm
S-III-O-0655 precision gear grinding slewing drive with three-stage gearboxes used for intelligent manufacturing workshop equipment, the customer uses ordinary motor to drive the slewing drive to rotate and stop when it reaches the specified position. The output speed of the slewing drive is required to be very low and the turntable should not have a large shaking after reaching the specified position.
According to the customer’s requirements, Unique Transmission recommended the 0655 slewing drive of the III series for the customer.In order to reduce the shaking of the rotary table, the slewing drive adopts zero clearance. The teeth are quenched and then ground to ensure that the slewing drive has a small tooth clearance, which ensures that the rotary table has only a small waggle after the motor is braked, which meets the customer’s requirements.
In the process of slewing drive selection and design, different slewing drives should be selected according to the specific working conditions and different precision and configuration. The ultimate goal is to provide customers with cost-effective, simple and reliable slewing drive products.
