Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number irfr9024ntr
BRAND International Rectifier [IR]
Packaging d-pak
Date code 11+
Price 0.145~0.15usd
Summary 55V, Single P-Channel, HEXFET Power MOSFET, D-Pak, -11A, 38W, Surface Mount
Description as follow:
The IRFR9024NTR is a Single P-Channel HEXFET Power MOSFET. It utilizes advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that the IRFR9024NTR is well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications.
Parametrics
IRFR9024NTR absolute maximum ratings: (1)Continuous Drain Current, VGS @ -10V:-11A; (2)Continuous Drain Current, VGS @ -10V:-8A; (3)Pulsed Drain Current:-44A; (4)Power Dissipation:38W; (5)Linear Derating Factor:0.30W/℃; (6)Gate-to-Source Voltage:±20V ; (7)Single Pulse Avalanche Energy:62mJ; (8)Avalanche Current:-6.6A; (9)Repetitive Avalanche Energy:3.8mJ; (10)Peak Diode Recovery dv/dt:-10V/ns; (11)Operating Junction and Storage Temperature Range:-55 to +150℃.
Features
IRFR9024NTR features: (1)Ultra Low On-Resistance; (2)P-Channel; (3)Surface Mount; (4)Advanced Process Technology; (5)Fast Switching; (6)Fully Avalanche Rated.
Diagrams
