Product Description:
Model: S-I-O-0240
Type: spur gear slewing drive
Slewing drive gear ratio: 5.80
Rated output torque:
3KN.M
Rotation center diameter: 235mm
Total height with adapter flange: 135mm
Gear backlash ≤0.30mm
S-I-O-0240 spur gear slewing drives with ordinary geared motors used in automated workshops. The customer’s requirements for the slewing drives are relatively simple, only the loads are required and there are no requirements for the slewing angles.
We designed this type of slewing drives according to customer’s requirements. The installation sizes of the slewing drives can be customized according to customer’s requirements. The input end sizes of the slewing drives are suitable for the customer’s ordinary geared motors. The output flange sizes of the ordinary geared motors are generally relatively large. When designing the adapter flanges, it is necessary to pay attention not to interfere with the inner ring mounting bolts of the slewing drives.
This kinds of slewing drive slewing assemblies with common geared motors have relatively low costs and are widely used. At the same time, they can meet the needs of customers to carry, rotate and reduce the speed of the motor.
The slewing drives have their own gear ratios, compact structure, high degree of integration, dustproof and waterproof, greases are sealed inside the slewing drives, not easy to be polluted, not easy to volatilize loss, and can be used without maintenance in applications with low speed or low frequency of use.
