Product Description:
LF58 Dual pressure switches is usually used with fluorinated refrigerants to control the pressure of
compressor in refrigeration system. It can also be used in air and water. It provide two pressure set points in one switch. Several models are available with drip-proof enclosure for marine application or in explosion-proof enclosure for special applications. Various conatact functions are available. Internal Micro-swith ensures reliable switching. It is provided standard Mounting Bracket.
Media Refrigerant, Air, Water, Oil
Media Temperature -10 C to 120 C
Connection M12X1.25, 7/16-20UNF
other connection is available on request
Contact Arrangement SPDT
Electrical Rating: Non-Inductive:
20a @125vac, 10a@ 250 vac
Inductive:
fla: 15a @ 125vac, 8a @250vac
lra: 72a
