Max474esa Maxim 8-soic, Dual 10 Mhz, Single-supply
Posted at: Offers to Sell and Export | Posted on: Monday 24 June 2013 2:53 am | Poster last visit: Friday 26 July 2013 |
Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number max474esa
BRAND Maxim Integrated Products [Maxim]
Packaging 8-soic
Date code 11+
Price 0.4~0.56usd
Summary 8-SOIC, dual 10 MHZ, single-supply, unity-gain-stable op amp, rail-to-rail output swing, +3V
Description as follow:
The MAX474ESA is a dual 10 MHZ, single-supply (2.7V to 5.25V), unity-gain-stable op amp with rail-to-rail output swing. Each op amp guarantees a 10MHz unity-gain bandwidth, 15V/μs slew rate, and 600Ω drive capability while typically consuming only 2mA supply current. In addition, the input range includes the negative supply rail and the output swings to within 50mV of each supply rail.
Parametrics
MAX474ESA absolute maximum ratings: (1)Supply Voltage (VCC - VEE): 7V; (2)Input Voltage (IN+, IN-, IN_+, IN_-): (VCC + 0.3V) to (VEE - 0.3V); (3)Output Short-Circuit Duration: Continuous; (4)8-Pin Plastic DIP (derate 9.09mW/℃ above +70): 727mW ; (5)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW; (6)8-Pin μMAX (derate 4.1mW/℃ above +70℃): 330mW; (7)8-Pin CERDIP (derate 8.00mW/℃ above +70): 640mW; (8)14-Pin Plastic DIP (derate 10.00mW/℃ above +70): 800mW; (9)Operating Temperature Range: -40 to 85℃; (10)Storage Temperature Range: -65 to +160℃; (11)Lead Temperature (soldering, 10sec): +300℃.
Features
MAX474ESA features: (1)15V/μs Min Slew Rate; (2)+3V Single-Supply Operation; (3)Guaranteed 10MHz Unity-Gain Bandwidth; (4)2mA Supply Current per Amplifier; (5)nput Range Includes Negative Rail; (6)Outputs Short-Circuit Protected; (7)Rail-to-Rail Output Swing (to within ±50mV); (8)μMAX Package (the smallest 8-pin SO).
Diagrams
Company Contact:
Contact Name: John
Company Name: Excellent Integrated System Limited (eis Limited)
Email:
Tel: 00852-30777742
Fax: 00852-30777843
Street Address: Rm 906, Workingberg
Comm Bldg, 41-47 Marble Rd, Hong Kong
Member name: EISLIMITED
Country: Hong Kong
Member Since: 29 August 2012
Total Leads: 537 EISLIMITED Import Export Business Leads
Business focus: Electronic Components, Active Component, Integrated Circuit, Semiconductor, Chips
Chat:
Verify: Safe Import Export Tips
