Mc68hc11e9 Freescale Semiconductor, Programming Reference Guide, Qfp-64
Posted at: Offers to Sell and Export | Posted on: Saturday 22 September 2012 1:57 am | Poster last visit: Friday 26 July 2013 |
Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number mc68hc11e9
BRAND Freescale Semiconductor, Inc [Freescale]
Packaging qfp-64
Date code 11+
Price 3.5~6usd
Summary Programming Reference Guide, QFP-64, -0.3 to +7.0 V Supply voltage, 25 mA, Real-time interrupt circuit
Description as follow:
The MC68HC11E9 is a peripheral interface (SPI). It is an independent communication subsystem, allows the MCU to communicate synchronously with peripheral devices. The SPI is also capable of inter-processor communication in a multiple master system. The MC68HC11E9 system can be configured as either a master or a slave device. When configured as a master, data transfer rates can be as high as one-half the E-clock rate (1.5 Mbits per second for a 3-MHz bus frequency). When configured as a slave, data transfers can be as fast as the E-clock rate (3 Mbits per second for a 3-MHz bus frequency).
Parametrics
MC68HC11E9 absolute maximum ratings: (1)Supply voltage VDD: -0.3 to +7.0 V; (2)Input voltage VIn: -0.3 to +7.0 V; (3)Current drain per pin, ID: 25 mA; (4)Storage temperature TSTG: -55 to +150 ℃.
Features
MC68HC11E9 features: (1)M68HC11 CPU; (2)Power-saving stop and wait modes; (3)Low-voltage devices available (3.0.5 Vdc); (4)0, 256, 512, or 768 bytes of on-chip RAM, data retained during standby; (5)0, 12, or 20 Kbytes of on-chip ROM or EPROM; (6)0, 512, or 2048 bytes of on-chip EEPROM with block protect for security; (7)2048 bytes of EEPROM with selectable base address in the MC68HC811E2; (8)Asynchronous non-return-to-zero (NRZ) serial communications interface (SCI); (9)Additional baud rates available on MC68HC(7)11E20; (10)Synchronous serial peripheral interface (SPI); (11)8-channel, 8-bit analog-to-digital (A/D) converter; (12)16-bit timer system:; (13)Three input capture (IC) channels; (14)Four output compare (OC) channels; (15)One additional channel, selectable as fourth IC or fifth OC; (16)8-bit pulse accumulator; (17)Real-time interrupt circuit.
Diagrams
Company Contact:
Contact Name: John
Company Name: Excellent Integrated System Limited (eis Limited)
Email:
Tel: 00852-30777742
Fax: 00852-30777843
Street Address: Rm 906, Workingberg
Comm Bldg, 41-47 Marble Rd, Hong Kong
Member name: EISLIMITED
Country:
Hong Kong
Member Since: 29 August 2012
Total Leads: 537 EISLIMITED Import Export Business Leads
Business focus: Electronic Components, Active Component, Integrated Circuit, Semiconductor, Chips
Chat:
Verify: Safe Import Export Tips
