Motorized Screw Jack Accurate Positioning Solar Panel Tracking System
Posted at: Offers to Sell and Export | Posted on: Thursday 20 June 2013 4:45 am | Poster last visit: Tuesday 25 December 2018 |
Product Category: Main
» Musical Instruments and Games and Toys and Arts and Crafts and Educational Equipment and Materials and Accessories and Supplies
» Developmental and professional teaching aids and materials and accessories and supplies
» Energy and power physics materials
» Solar collecting devices
» Motorized Screw Jack Accurate Positioning Solar Panel Tracking System
Product Description:
Motorized screw jack accurate positioning solar panel tracking system, which is the ideal solutions of
solar panel tracking system. Because motorized screw jack is equipped with self-locking acme screw, protective pipe, bellows boot, limit switches, swivel plate, swivel mounting base, electric motor and gear reducer. Which solves the problem that solar panel tracking system must be highly rugged and can withstand wind force and weather, function reliably, maintenance free for many years, safety self locking and accurate positioning tracking movement. If motorized screw jack with high accuracy ball screw, must be equipped with brake mechanism.
Buyer: Canada Government Energy Project
Regular motorized screw jack selected model JT-10T-US-1500-L-II-M1-PP/BB/EM/GR/LS/SP
10ton static lifting force, upright type jack, translating screw configuration, customized threaded end matches female rod end(clevis end), exact 1200mm travel length(1500mm=travel stroke+bellows boot retract length+swivel plate thickness), low worm gear ratio 32:1, left side flange adapter, protective pipe, bellows boot, electric motor, gear reducer, limit switches and swivel plate. Normaly, using 24 volt DC gear motor driven screw jack, travel speed from 150mm/min to 300mm/min with gear reduction mechanism.
Another type motorized screw jack selected model JT-10T-UK-1500-L-IV-M1-PP/BB/EM/GR/LS/SP
10ton static lifting force, upright type jack, keyed screw configuration, threaded end, exact 1200mm travel length(1500mm=travel stroke+bellows boot retract length+swivel plate thickness), low worm gear ratio 32:1, left side flange adapter, protective pipe, bellows boot, electric motor, gear reducer, limit switches and swivel plate. Using single phase or three phase AC gear motor driven screw jack, travel speed from 150mm/min to 300mm/min with gear reduction mechanism.
Company Contact:
Contact Name: Warren Lee
Company Name: Jacton Electromechanical Ltd
Email:
Tel: +86 769 81585852
Fax: +86 769 81620195
Street Address: No.1, Langwei Road,
Changan, Dongguan, Guangdong,
China
Member name: screwjack
Country:
China
Member Since: 17 May 2010
Total Leads: 916 screwjack Import Export Business Leads
Business focus: Screw Jack, Bevel Gearbox, Screw Jack Lift System
Chat:
Verify: Safe Import Export Tips
