Pic18f67j10 Microchip 64tqfp, Flash Microcontroller, 40mhz
Posted at: Offers to Sell and Export | Posted on: Thursday 18 October 2012 6:32 am | Poster last visit: Friday 26 July 2013 |
Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number pic18f67j10-i/pt
BRAND Microchip
Packaging tqfp
Date code 10+
Price 2.26~2.35usd
Summary 64TQFP, Flash Microcontroller, 40MHz, 2 V ~ 3.6 V, 8-Bit, PIC18F67J10-I/PT
Description as follow:
The PIC18F67J10-I/PT is a 64-Pin, High-Performance, 1-Mbit Flash Microcontroller with nanoWatt Technology.
Parametrics
PIC18F67J10-I/PT absolute maximum ratings: (1)Ambient temperature under bias: -40 to +125℃; (2)Storage temperature: -65 to +150℃; (3)Voltage on any digital-only I/O pin or MCLR with respect to VSS (except VDD): -0.3V to 6.0V; (4)Voltage on any combined digital and analog pin with respect to VSS (except VDD): -0.3V to (VDD + 0.3V); (5)Voltage on VDDCORE with respect to VSS: -0.3V to 2.75V; (6)Voltage on VDD with respect to VSS: -0.3V to 3.6V; (7)Total power dissipation: 1.0W; (8)Maximum current out of VSS pin: 300 mA; (9)Maximum current into VDD pin: 250 mA; (10)Maximum output current sunk by any PORTB and PORTC I/O pin: 25 mA; (11)Maximum output current sunk by any PORTD, PORTE and PORTJ I/O pin: 8 mA; (12)Maximum output current sunk by any PORTA, PORTF, PORTG and PORTH I/O pin: 4 mA; (13)Maximum output current sourced by any PORTB and PORTC I/O pin: 25 mA; (14)Maximum output current sourced by any PORTD, PORTE and PORTJ I/O pin: 8 mA; (15)Maximum output current sourced by any PORTA, PORTF, PORTG and PORTH I/O pin: 4 mA; (16)Maximum current sunk by all ports: 200mA; (17)Maximum current sourced by all ports: 200 mA.
Features
PIC18F67J10-I/PT features: (1)Operating voltage range: 2.0V to 3.6V; (2)5.5V tolerant input (digital pins only); (3)On-chip 2.5V regulator; (4)Low-power, high-speed CMOS Flash technology; (5)C compiler optimized architecture: Optional extended instruction set designed to optimize re-entrant code; (6)Priority levels for interrupts; (7)8 x 8 Single-Cycle Hardware Multiplier; (8)Extended Watchdog Timer (WDT): Programmable period from 4 ms to 131s; (9)Single-Supply In-Circuit Serial Programming (ICSP) via two pins; (10)In-Circuit Debug (ICD) with three Break points via two pins; (11)High-current sink/source 25 mA/25 mA (PORTB and PORTC); (12)Four programmable external interrupts; (13)Four input change interrupts; (14)Two Capture/Compare/PWM (CCP) modules; (15)Two Crystal modes, up to 40 MHz for VDD > 2.15V; (16)4x Phase Lock Loop (PLL); (17)Two External Clock modes, up to 40 MHz; (18)Internal 31 kHz oscillator; (19)Secondary oscillator using Timer1 @ 32 kHz; (20)Two-Speed Oscillator Start-up; (21)Fail-Safe Clock Monitor: Allows for safe shutdown if peripheral clock stops.
Diagrams
Company Contact:
Contact Name: John
Company Name: Excellent Integrated System Limited (eis Limited)
Email:
Tel: 00852-30777742
Fax: 00852-30777843
Street Address: Rm 906, Workingberg
Comm Bldg, 41-47 Marble Rd, Hong Kong
Member name: EISLIMITED
Country:
Hong Kong
Member Since: 29 August 2012
Total Leads: 537 EISLIMITED Import Export Business Leads
Business focus: Electronic Components, Active Component, Integrated Circuit, Semiconductor, Chips
