Product Description:
One Set Razor Wire Making Machine include: A and B Two parts.
A: Punching machine part:
It use for
cut the steel strip, and make steel strip into razor blade, machine can produce different shapes and sizes strip by changing mold.
B: Forming machine part:
It is used for warp steel wire into razor blade then wind up razor blade wire in coil.
Razor Wire Making Machine Specific Size
Model 5 Strips Punching Machine 9 Strips Punching Machine Coiling Machine
Working Pressure 25T 40T
Voltage 380V/50HZ or as your request
Power 2.2kw 2.2kw 1.5kw
Producing Speed 220-280m / h 220-280m / h 80kg / h
Weight 1500KG 2200KG 300KG
Thickness of Sheet 0.5±0.05(mm) 0.5±0.05(mm) --
Diameter of Wire -- -- 2.5mm
Dimension(mm) 1200 * 1000 * 1900 1100 * 1000 * 2000 100 * 750 * 1200
Raw material GI sheet; Hot dipped galvanized steel sheet; Stainless steel sheet, etc.
