Rb4510 Crossed Roller Bearing Thk Standard 45x70x10mm
Posted at: Offers to Sell and Export | Posted on: Tuesday 2 September 2014 7:35 am | Poster last visit: Thursday 12 February 2015 |
Product Category: Main
» Manufacturing Components and Supplies
» Bearings and bushings and wheels and gears
» Bearings
» Roller bearings
» Rb4510 Crossed Roller Bearing Thk Standard 45x70x10mm
Product Description:
RB4510 Crossed roller bearing THK Standard 45x70x10mm
A. Bearing Parameter AND Model Table
Structure:Crossed
Roller
Type:Crossed Roller bearing
Brand Name:BYC
Model Number:RB4510
Size (Metric):
ID (Inner Diameter, Bore)= 45 mm
OD (Outer Diameter) =70 mm
Width (Height, thickness) = 10 mm
Precision Rating:P5/P4/P2
Radial load rating Cr(KN): 8.62
Weight(Kg): 0.17
Material:GCr15 bearing steel
Types of Lubrication:Grease
Rotation part: Inner ring rotating (not outer ring)
RB/CRB/CRBC Standard Type (separable Outer Ring for Inner Ring Rotation)
RB standard type is a bearing with thinnest possible inner and outer rings because the outer ring is split while the inner ring is integrated into the main body. It is being used in cases where a high rotational accuracy of the inner ring is required.
B. Feature of Crossed Roller Bearing
1.High accuracy and load capacity.
2. Withstands force in any direction, Alternately crossed rollers 45 degree angle.
3. Easy Installation and get used to small spaces.
4. Factory PERLOAD for minimum axial play and low coefficient of friction.
C. Product Application
1.Industrial Robotic arm, Reducer drive
2.Turntable, NC rotary table
3.Rotation part of Machine tools
4.Inspection instrument, Medical equipment
5.Aviation equipment, Military radar etc
Rb4010, rb4510, rb5013, rb6013, rb7013, rb8016, rb9016, rb10016, rb10020, rb11012, rb11015, rb11020, rb12016, rb12025, rb13015, rb13025, rb14016, rb14025, rb15013, rb15025, rb15030, rb16025, rb17020, rb18025, rb19025, rb20025, rb20030, rb20035, rb22025, rb24025, rb25025, rb25030, rb25040, rb30025, rb30035, rb30040, rb35020, rb40035, rb40040, rb45025, rb50025, rb50040, rb50050, rb60040, rb70045, rb80070, rb90070, rb1000110, rb1250110
G. Shipping And Payment
1. Industrial Neutral Packing, Package as your requirements.
2. Small size Bearings:Plastic vacuum packaging bag+Paper Box/Neutral Carton
3.Large size Bearings:Plastic film+Pergamyn paper+Roll tape+Wooden Box
4.Shipping:By air or By sea:DHL/TNT/UPS/EMS etc
5.Min.Order Quantity: 5 Piece/Pieces
6.Supply Ability: 1500 Units/Year
7.Port:SHANGHAI, HK, Guangzhou
8.Payment Terms:T/T
Company Contact:
Contact Name: Yang Liu
Company Name: Luoyang Boying Bearing Co., Ltd
Email:
Tel: 86-379-62275175
Fax: 86-379-62275812
Street Address: Yingzhuang Industry
Park Wangchaoling Laocheng
Luoyang, Henan 471000
China
Website: https://bycbearing.en.alibaba.com
Member name: CrossedRollerBearingsBYC
Country:
China
Member Since: 02 September 2014
Total Leads: 42 CrossedRollerBearingsBYC Import Export Business Leads
Business focus: Crossed Roller Bearing, Rotary Table Bearing, Tapered Roller Bearing, Roller Bearing, Angular Contact Ball Bearing
Chat:
Verify: Safe Import Export Tips
