Product Description:
S&A recirculating chiller CW-6100AT for Raycus 500W Laser
S&A CW-6100AT dual temperature and
dual pump series is high-precision compression refrigeration water chiller, with intelligent temperature control, completed configuration, perfect protection and alarm system. It is fit for cooling Raycus 500W laser.
S&A CW-6100AT is able to cool the fiber laser and optic lense at the same time, multiple use for saving cost, space and manual move, quiteconvenient for the user.
S&A water chiller CW-6100AT features
1. 4200W cooling capacity; optional environmental refrigerant;
2. ±0.5℃ precisely temperature control;
3. The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions;
4. Dual temperature and dual pump to satisfy different needs of fiber laser device and the lens;
5. With Ion adsorption filtrating and test functions conform to fiber laser device operating requirements;
6. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;
7. Multiple power specifications; CE approval; RoHS\REACH approval;
8. Long working life and easy operation;
9. Optional heater and water filter.
CW-6100AT parameter:
Voltage: 220V; Frequency: 50/60Hz; Refrigerant: R-22 / R-410a
Pump power: 0.1KW+0.55KW; Tank capacity:4L+12L
Max. lift:25M+36M; Max. flow: 16L/min+70L/min
N.W: 90Kgs; G.W: 100Kgs;
Dimension : 78 X 47 X 89 cm (L X W X H); Packing dimension: 87 X 60 X 109 cm(L X W X H)
About S&A Brand
S&A produces more than 60000 units of industrial chillers by year, we always insist on”Quality First” in design and production.
“S&A” and “TEYU” have been enjoying high reputation among hundreds of manufacturers which are from both at home and abroad, and export rate reaches above 60%.
