Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number ad822arz
BRAND AVX Corporation
Packaging 8-soic
Date code 07+
Price 2.5~4usd
Summary op amp, Slew rate of 3.0 V/ms, 8-SOIC
Description as follow:
The AD822ARZ is one member of the AD822 series.The AD822 is a dual precision, low power FET input op amp that can operate from a single supply of 3.0 V to 36 V or dual supplies of ±1.5 V to ±18 V. It has true single-supply capability with an input voltage range extending below the negative rail, a llowing the AD822 to accommodate input signals below ground in the single-supply mode. Output voltage swing extends to within 10 mV of each rail, providing the maximum output dynamic range.
Parametrics
Absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Internal Power Dissipation: PDIP (N): Observe Derating Curves; SOIC (R): Observe Derating Curves; (3)Input Voltage: (+VS + 0.2 V) to -(20 V + VS); (4)Output Short Circuit Duration: Indefinite; (5)Differential Input Voltage: ±30 V; (6)Storage Temperature Range (N): –65℃ to +125℃; (7)Storage Temperature Range (R, RM): –65℃ to +150℃; (8)Operating Temperature Range AD822 A Grade and B Grade: –40℃ to +85℃; (9)Lead Temperature Range (Soldering, 60 sec): 260℃.
Features
Features:(1)output swings rail-to-rail; (2)input voltage range extends below ground; (3)single-supply capability from 3 V to 36 V; (4)dual-supply capability from ±1.5 V to ±18 V; (5)800 μA maximum quiescent current per amplifier ; (6)unity gain bandwidth: 1.8 MHz; (7)Slew rate of 3.0 V/μs; (8)800 μV maximum input offset voltage; (9)2 μV/℃ typical offset voltage drift; (10)25 pA maximum input bias current.
Diagrams
