Product Description:
An essential piece of kit for the majority of vehicle owners - save time and money with this handy palm
sized MaxScan 405 VAG code reader which enables you to troubleshoot any problems in your vehicle by reading the Diagnostic Trouble Codes (DTC's) that appear when the "check engine" light is showing.
DTC's are codes that are stored by the car's in-board computer system in response to a vehicle issue. Codes relate to a particular problem and are made up of a 5 digit alpha-numeric sequence and are used as a guide to help locate the fault in order for you to fix the vehicle.
This scanner reads and erases all DTC codes of the engine, airbag, ABS and A/T and turns off the MIL lights of the engine, airbags, ABS and automatic transmission
Benefits:
--Reads and erases DTC's and re-sets 'Check Engine' light
--Reads both generic and manufacturer specific codes
--Identifies and displays pending codes
--Determines MIL status
--Reads freeze frame data
--Retrieves the VIN on 2002+ vehicles that support Mode 9
--Displays I/M readiness status
--Large 128 x 64 pixel LCD screen with back light and contrast adjustment
Extra Benefits Specific to Audi, Seat, Skoda and VW's:
--Reads and erases DTC's and re-sets service lights on the ABS, airbags, automatic transmission, climate control, engine immobilizer plus others
--Resets Oil Service Light
--Retrieves the VIN
--Turns off MIL lights for the ABS, auto transmission, airbags and engine as well as the majority of the other systems
Will the MaxScan 405 work with my car?
This reader works with the majority of OBD 2, EOBD and CAN-BUS vehicles manufactured worldwide including the following:
Acura Kia
Asuna Land Rover
Audi Lexus
Bentley Lincoln
Buick Mazda
Cadillac Mercury
Chevrolet Mini
Chevy Murkur
Chrysler Nissan
Citroen Oldsmobile
Daewoo Opel
Dodge Peugeot
Eagle Plymouth
Fiat Pontiac
Ford Porsch
Geo Renault
GM Rover
GMC Saab
Honda Saturn
Hummer Scion
Hyundai
Infinity
Isuzu
Jaguar
Jeep
Plus VAG vehicles such as:Audi, Volkswagen, Seat and Skoda vehicles manufactured since 1990 - even with newer models that require a direct CAN connection
If your car has a 16 pin 'OBD style' data link connector (DTC) the code reader is compatible, however if it has an older-style 2x2 DTC then it will depend whether there are 3 or 4 wires connecting to the pins. If there are 4 wires then the scanner will work but if there are only 3 wires, leaving one pin disconnected, then, sorry, but this product will not work.
If your vehicle is the 2x2 DTC 4 wire style you will need a 2x2 cable adapter. (Not included in this sale)
The scanner works with the following protocols:
--J1850 PWM
--J1850 VPW
--KPW 2000
--ISO 14230-04
--ISO 9141
For specific compatibility information please check your vehicle's user guide or with the manufacturer. Please do bear in mind that while we do our very best to provide accurate information we cannot be held responsible in the unlikely event that this code reader does not work with a certain car or van.
Specifications:
--Display: backlit 128 x 64 pixel display with contrast adjustment
--Operating temperature: 0 to 50¡ãC (-32 to 122¡ãF)
--Storage temperature: -20 to 70¡ãC (-4 to 158¡ãF)
--Power: 8.0 to 15.0V - provided by vehicle's battery
--Dimensions: 17.5 x 9 x 3cm (7 x 3.5 x 1 ")
The MaxScan 405 is brand new and is supplied with OBD2 cable, serial cable (for upgrading the scanner via the internet), nylon storage/carry case and instruction manual
We're positive you'll have many happy years of use from this product, however we understand things can occasionally go wrong, which is why we are pleased to offer a superior 1 Year Warranty with this sale that covers you in the unlikely event that you experience any problems.
