Sell Ft232rl Ftdi, Usb Uart Interface Circuit Devices
Posted at: Offers to Sell and Export | Posted on: Friday 31 August 2012 3:14 am | Poster last visit: Friday 26 July 2013 |
Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number ft232rl
Brand ftdi
Packaging ssop-28
Date code 11+
Price 2.06~2.99usd
Summary Incorporating Clock Generator Output, SSOP28, Single chip USB, 256 byte receive buffer
Description as follow:
The FT232RL is the latest device to be added to FTDI range of USB UART interface Integrated Circuit Devices. The FT232RL is a USB to serial UART interface with optional clock generator output, and the new FTDIChip-ID. security dongle feature. In addition, asynchronous and synchronous bit bang interface modes are available. USB to serial designs using the FT232RL have been further simplified by fully integrating the external EEPROM, clock circuit and USB resistors onto the device. The FT232RL adds two new functions compared with its predecessors, effectively making it a 3-in-1 chip for some application areas. The internally generated clock (6MHz, 12MHz, 24MHz, and 48MHz) can be brought out of the device and used to drive a microcontroller or external logic. A unique number (the FTDIChip-ID.) is burnt into the device during manufacture and is readable over USB, thus forming the basis of a security dongle which can be used to protect customer application software from being copied.
Parametrics
FT232RL absolute maximum ratings: (1)Storage Temperature: -65℃ to 150℃; (2)Floor Life (Out of Bag) At Factory Ambient ( 30℃ / 60% Relative Humidity): 168 Hours (IPC/JEDEC J-STD-033A MSL Level 3 Compliant); (3)Ambient Temperature (Power Applied): -40℃ to 85℃; (4)Vcc Supply Voltage: -0.5 to +6.00V; (5)D.C. Input Voltage - USBDP and USBDM: -0.5 to +3.8V; (6)D.C. Input Voltage - High Impedance Bidirectionals: -0.5 to +(Vcc +0.5)V; (7)D.C. Input Voltage - All other Inputs: -0.5 to +(Vcc +0.5)V; (8)D.C. Output Current - Outputs: 24mA; (9)DC Output Current - Low Impedance Bidirectionals: 24 mA; (10)Power Dissipation (Vcc = 5.25V): 500mW.
Features
FT232RL features: (1)Single chip USB to asynchronous serial data transfer interface; (2)Entire USB protocol handled on the chip - No USB-specific firmware programming required.; (3)UART interface support for 7 or 8 data bits, 1 or 2 stop bits and odd / even / mark / space / no parity.; (4)Fully assisted hardware or X-On / X-Off software handshaking. New configurable CBUS I/O pins.; (5)Auto transmit buffer control for RS485 applications.; (6)Transmit and receive LED drive signals. New CBUS bit bang mode option.; (7)Integrated 1024 Bit internal EEPROM for storing USB VID, PID, serial number and product description strings, and CBUS I/O configuration.; (8)Device supplied preprogrammed with unique USB serial number.; (9)Support for USB suspend and resume. 3.3V to 5.25V Single Supply Operation.; (10)Low operating and USB suspend current.; (11)Low USB bandwidth consumption.; (12)UHCI / OHCI / EHCI host controller compatible; (13)USB 2.0 Full Speed compatible. -40℃ to 85℃ extended operating temperature range.; (14)Available in compact Pb-free 28 Pin SSOP and QFN-32 packages (both RoHS compliant).
Diagrams
Company Contact:
Contact Name: John
Company Name: Excellent Integrated System Limited (eis Limited)
Email:
Tel: 00852-30777742
Fax: 00852-30777843
Street Address: Rm 906, Workingberg
Comm Bldg, 41-47 Marble Rd, Hong Kong
Member name: EISLIMITED
Country:
Hong Kong
Member Since: 29 August 2012
Total Leads: 537 EISLIMITED Import Export Business Leads
Business focus: Electronic Components, Active Component, Integrated Circuit, Semiconductor, Chips
Chat:
