Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number max3232cpe
BRAND Maxim Integrated Products [Maxim]
Packaging dip-16
Date code 10+
Price 1.27~1.33usd
Summary RS232 Transceiver, DIP-16, 3.0V to 5.5V, MAX3232CPE, Maxim Integrated Products
Description as follow:
The MAX3232CPE transceiver has a proprietary low-dropout transmitter output stage enabling true RS-232 performance from a 3.0V to 5.5V supply with a dual charge pump. The device require only four small 0.1μF external chargepump capacitors. The MAX3232CPE is guaranteed to run at data rates of 120kbps while maintaining RS-232 output levels. The MAX3232CPE has 2 receivers and 2 drivers. The MAX3232CPE is pin, package, and functionally compatible with the industry-standard MAX242 and MAX232, respectively. The applications of it are Notebook, Subnotebook, and Palmtop Computers, High-Speed Modems, Battery-Powered Equipment, Hand-Held Equipment, Peripherals, Printers.
Parametrics
MAX3232CPE absolute Maximum Ratings: (1)VCC: -0.3V to +6V; (2)V+ (Note 1): -0.3V to +7V; (3)V- (Note 1): +0.3V to -7V; (4)V+ + V- (Note 1): +13V; (5)Input Voltages T_IN, SHDN, EN: -0.3V to +6V; (6)Input Voltages T_IN, MBAUD: -0.3V to (VCC + 0.3V); (7)Input Voltages T_IN, R_IN: ±25V; (8)Output Voltages T_OUT: ±13.2V; (9)Output Voltages R_OUT: -0.3V to (VCC + 0.3V); (10)Short-Circuit Duration T_OUT: Continuous; (11)Continuous Power Dissipation (TA = +70℃) 16-Pin Plastic DIP (derate 10.53mW/℃ above +70℃): 842mW; (12)Operating Temperature Ranges: 0℃ to +70℃; (13)Storage Temperature Range: -65℃ to +150℃; (14)Lead Temperature (soldering, 10sec): +300℃.
Features
MAX3232CPE features: (1)Low Supply Current: 300μA (MAX3222/MAX3232/MAX3241); (2)Guaranteed Data Rate: 120kbps (MAX3222/MAX3232/MAX3241); (3)1μA Low-Power Shutdown with Receivers Active(MAX3222/MAX3237/MAX3241); (4)Flow-Through Pinout (MAX3237); (5)Meets EIA/TIA-232 Specifications Down to 3.0V; (6)Guaranteed Mouse Driveability (MAX3241); (7)Pin Compatible with Industry-Standard MAX232 (MAX3232); (8)Guaranteed Slew Rate: 6V/μs (MAX3222/MAX3232/MAX3237/MAX3241).
Diagrams
