Sell Wm8198scds Wm8198scds Electronic Components, Analogue Front End / Digitiser Ic
Posted at: Offers to Sell and Export | Posted on: Monday 3 September 2012 2:11 am | Poster last visit: Friday 26 July 2013 |
Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number wm8198scds
BRAND Wolfson Microelectronics plc [Wolfson]
Packaging ssop-28
Date code 10+
Price 0.88~1.288usd
Summary analogue front end/digitiser IC, SSOP-28, GND - 0.3V to GND + 7V
Description as follow:
The WM8198SCDS is a 16-bit analogue front end/digitiser IC which processes and digitises the analogue output signals from CCD sensors or Contact Image Sensors (CIS) at pixel sample rates of up to 6MSPS. The applications of the WM8198SCDS include Flatbed and sheetfeed scanners, USB compatible scanners, Multi-function peripherals, High-performance CCD sensor interface.
Parametrics
WM8198SCDS absolute maximum ratings: (1)Analogue supply voltage: GND - 0.3V to GND + 7V; (2)Digital supply voltages: GND - 0.3V to GND + 7V; (3)Digital ground: GND - 0.3V to GND + 0.3V; (4)Analogue grounds: GND - 0.3V to GND + 0.3V; (5)Digital inputs, digital outputs and digital I/O pins: GND - 0.3V to DVDD2 + 0.3V; (6)Analogue inputs (RINP, GINP, BINP) GND: - 0.3V to AVDD + 0.3V; (7)Other pins: GND - 0.3V to AVDD + 0.3V; (8)Operating temperature range: 0℃ +70℃; (9)Storage prior to soldering: 30℃ max / 85% RH max; (10)Storage temperature after soldering: -65℃ to +150℃; (11)Package body temperature (soldering, 10 seconds): +260℃; (12)Package body temperature (soldering, 2 minutes): +183℃.
Features
WM8198SCDS features: (1)16-bit ADC; (2)6MSPS conversion rate; (3)Low power ?212mW typical; (4)5V single supply or 5V/3.3V dual supply operation; (5)Single or 3 channel operation; (6)Correlated double sampling; (7)Dual Range Programmable Gain Amplifier (9-bit resolution); (8)Programmable offset adjust (8-bit resolution); (9)Programmable clamp voltage; (10)8 or 4-bit wide multiplexed data output formats; (11)Internally generated voltage references; (12)28-pin SSOP package; (13)Serial control interface.
Diagrams
Company Contact:
Contact Name: John
Company Name: Excellent Integrated System Limited (eis Limited)
Email:
Tel: 00852-30777742
Fax: 00852-30777843
Street Address: Rm 906, Workingberg
Comm Bldg, 41-47 Marble Rd, Hong Kong
Member name: EISLIMITED
Country:
Hong Kong
Member Since: 29 August 2012
Total Leads: 537 EISLIMITED Import Export Business Leads
Business focus: Electronic Components, Active Component, Integrated Circuit, Semiconductor, Chips
Chat:
