Specially Designed S-i-o-0641 Spur Gear Slewing Drive For Space Limitation
Posted at: Offers to Sell and Export | Posted on: Thursday 24 March 2022 11:01 am | Poster last visit: Monday 23 September 2024 |
Product Category: Main
» Commercial and Military and Private Vehicles and their Accessories and Components
» Transportation components and systems
» Drivetrain systems
» Drive shafts
» Specially Designed S-i-o-0641 Spur Gear Slewing Drive For Space Limitation
Product Description:
Specially designed S-I-O-0641 spur gear slewing drive for space limitation
Model: S-I-O-0641
Type:
Spur gear slewing drive
Slewing drive gear ratio: 12.20
Rated output torque: 5100N.M
Rotation center diameter: 641mm
Total height with adapter flange: 95mm
Gear backlash ≤0.30mm
S-I-O-0641 spur gear slewing drive is used for automation equipment. They are external gear type slewing drives, which are driven by gear motors to rotate. The gear motors are not in the form of flange output. The mounting surface of the gear motors and output bearings are distributed at 90 degrees. Due to space limitation, the flange steps cannot be used for positioning and the flange height must be reduced.
In order to reduce the flange height, we have adopted a special design to minimize the flange height to meet the customer's requirements. According to the particularity of the customer's gear motors, after discussing the assembly sequence and cooperation relationship with the customer, according to the discussion results, we have formulated a reasonable processing technology to ensure that the spur gear slewing drives can be smoothly installed and used in the customer's factory.
The processing, assembly and debugging were very smooth, and the 3 sets of spur gear slewing drives were packaged and sent to the customer's factory after passing the inspection. U-TRSM once again successfully completed the delivery of special customized products.
Company Contact:
Contact Name: Guoguo
Company Name: Unique Transmission Equipment（luoyang）co., Ltd
Email:
/
Tel: +86-379-64915181
Fax:
Street Address: No.22 Binhe Road,
New & High Tech Industry
Development Zone, Luoyang Area Of
China (henan) Pilot Free Trade Zone,
471000
Website: https://en.u-transmission.com
Member name: UniqueTransmission
Country:
China
Member Since: 16 June 2021
Total Leads: 196 UniqueTransmission Import Export Business Leads
Business focus: Slew Drive, Slewing Ring
Chat:
Verify: Safe Import Export Tips
Model: S-I-O-0641
Type:
Spur gear slewing drive
Slewing drive gear ratio: 12.20
Rated output torque: 5100N.M
Rotation center diameter: 641mm
Total height with adapter flange: 95mm
Gear backlash ≤0.30mm
S-I-O-0641 spur gear slewing drive is used for automation equipment. They are external gear type slewing drives, which are driven by gear motors to rotate. The gear motors are not in the form of flange output. The mounting surface of the gear motors and output bearings are distributed at 90 degrees. Due to space limitation, the flange steps cannot be used for positioning and the flange height must be reduced.
In order to reduce the flange height, we have adopted a special design to minimize the flange height to meet the customer's requirements. According to the particularity of the customer's gear motors, after discussing the assembly sequence and cooperation relationship with the customer, according to the discussion results, we have formulated a reasonable processing technology to ensure that the spur gear slewing drives can be smoothly installed and used in the customer's factory.
The processing, assembly and debugging were very smooth, and the 3 sets of spur gear slewing drives were packaged and sent to the customer's factory after passing the inspection. U-TRSM once again successfully completed the delivery of special customized products.
