Square Tube Roll Forming Machine

Posted at: Offers to Sell and Export | Posted on: Monday 31 October 2016 8:28 am | Poster last visit: Monday 31 October 2016 |

Product Category: Main » Industrial Manufacturing and Processing Machinery and Accessories » Industrial food and beverage equipment » Food preparation machinery » Forming machine » Square Tube Roll Forming Machine


Product Photo:

square tube roll forming machine

Similar Products Catalog:
Products Photos Catalog Square Tube Roll Photos Catalog

Product Description:

Technical Data

1. Machine specification: Forming thickness 2mm


2. Size: 65x 35 x 2mm

3. Forming speed:

0-10M/min (EXCLUDING CUTTING STOP TIME)

4. Forming roller: About 25 stations

5. Main motor power: 7.5KW

6. Hydraulic station power: 5.5KW

7. Roller material: Gcr15, HRC55

8. Main shaft material: 45# steel

9. Main axis dia.: 68mm

10. Hydraulic cutting pressure: 10-12Mpa

11. Cutting method: Hydraulic powered, cutting after roll forming.

12. Cutting blade material: Cr12 quenching treatment

13. Electrical controlling system: Whole line adopted PLC control Yasukawa, cut to length tolerance≤ 2mm

14. Voltage: 415V, 50HZ, 3phase

15. Size of machine: 10000mm*600mm*800mm



Company Contact:

WuxiTechwellMachinery photo
Contact Name: Joanna
Company Name: Wuxi Techwell Machinery Co., Ltd
Email: Email
Tel: 86-0510-83133431
Fax: 86-0510-83133431
Street Address: Chong An District
Wuxi, Jiangsu Province 214000
China
Member name: WuxiTechwellMachinery
Country: China-CN China
Member Since: 15 July 2016
Total Leads: 40 WuxiTechwellMachinery Import Export Business Leads
Business focus: Cold Roll Forming Machines, Insulated Sandwich Panels Machines, Slitting Cutting Machines
