Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number tlc59116ipwr
BRAND Texas Instruments [TI]
Packaging 28-tssop
Date code 10+
Price 2.1~5.5usd
Summary 16-Channel, Fm I2C-BUS, constant-current, LED sink driver, 28-TSSOP
Description as follow:
The TLC59116IPWR is an I2C bus controlled 16-channel LED driver that is optimized for red/green/blue/amber (RGBA) color mixing and backlight application for amusement products. Each LED output has its own 8-bit resolution (256 steps) fixed-frequency individual PWM controller that operates at 97 kHz, with a duty cycle that is adjustable from 0% to 99.6%. The TLC59116IPWR is one of the first LED controller devices in a new Fast-mode Plus (Fm+) family. Fm+ devices offer higher frequency (up to 1 MHz) and longer, more densely populated bus operation (up to 4000 pF).
Parametrics
TLC59116IPWR absolute maximum ratings: (1)VCC Supply voltage range: 0 V to 7 V; (2)VI Input voltage range: –0.4 V to VCC + 0.4 V; (3)VO Output voltage range: –0.5 V to 20 V; (4)IO Output current: 120 mA; (5)qJA Thermal impedance, junction to free air(2): 61.7 ℃/W; (6)PD Power dissipation: See Dissipation Ratings; (7)TJ Junction temperature range: –40℃ to 150℃; (8)Tstg Storage temperature range: –55℃ to 150℃.
Features
TLC59116IPWR features: (1)16 LED Drivers (Each Output Programmable at Off, On, Programmable LED Brightness, or Programmable Group Dimming/Blinking Mixed With Individual LED Brightness) ; (2)16 Constant-Current Open-Drain Output Channels; (3)Internal Power-On Reset; (4)Noise Filter on SCL/SDA Inputs; (5)No Glitch on Power Up; (6)Active-Low Reset; (7)3.3-V or 5-V Supply Voltage; (8)Offered in 28-pin TSSOP (PW) Package; (9)–40℃ to 85℃ Operation.
Diagrams
