Product Description:
Excellent Integrated System LIMITED (EIS LIMITED), Established in 1991, is a professional independent
stocking distributor of electronic components and specialize in buying the EXCESS STOCK from the original equipment manufacturers (OEMs), Contract equipment manufacturers (CEMs), and many other factories. EIS has gained good experiences in Excess Inventory Management through its development over 20 years and has become the reliable partner for the domestic and foreign OEM manufacturers. If any inquiry and question, please email us:
Part number tps54610pwp
BRAND Texas Instruments [TI]
Packaging ssop-28
Date code 10+
Price 4.5~9usd
Summary 28 pin HTSSOP, 3V to 6V, 6A, synchronous buck, PWM switcher
Description as follow:
As a member of the SWIFT family of dc/dc regulators, the TPS54610PWP low-input voltage high-output current synchronous buck PWM converter integrates all required active components. Included on the substrate with the listed features are a true, high performance, voltage error amplifier that enables maximum performance and flexibility in choosing the output filter L and C components; an under-voltage-lockout circuit to prevent start-up until the input voltage reaches 3 V; an internally or externally set slow-start circuit to limit inrush currents; and a power good output useful for processor/logic reset, fault signaling, and supply sequencing. The TPS54610PWP is available in a thermally enhanced 28-pin TSSOP (PWP) PowerPAD. package, which eliminates bulky heatsinks. TI provides evaluation modules and the SWIFT. designer software tool to aid in quickly achieving high-performance power supply designs to meet aggressive equipment development cycles.
Parametrics
TPS54610PWP absolute maximum ratings: (1)Input voltage range, VI: VIN, SS/ENA, SYNC: -0.3 V to 7 V; RT: -0.3 V to 6 V; VSENSE: -0.3 V to 4V; BOOT : -0.3 V to 17 V; (2)Output voltage range, VO, VBIAS, COMP, PWRGD: -0.3 V to 7 V; PH: -0.6 V to 10 V; (3)Source current, IO: PH Internally Limited; COMP, VBIAS: 6 mA; (4)Sink current, IS: PH 12 A; COMP: 6mA; SS/ENA, PWRGD: 10mA; (5)Voltage differential AGND to PGND: ±0.3 V; (6)Operating virtual junction temperature range, TJ: -40 to 125 ℃; (7)Storage temperature, Tstg: -65 to 150 ℃; (8)Lead temperature 1, 6 mm (1/16 inch) from case for 10 seconds: 300 ℃.
Features
TPS54610PWP features: (1)30-mΩ, 12-A Peak MOSFET Switches for High Efficiency at 6-A Continuous Output Source or Sink Current; (2)Adjustable Output Voltage Down To 0.9 V With 1.0% Accuracy; (3)Wide PWM Frequency: Fixed 350 kHz, 550 kHz or Adjustable 280 kHz to 700 kHz; (4)Synchronizable to 700 kHz; (5)Load Protected by Peak Current Limit and Thermal Shutdown; (6)Integrated Solution Reduces Board Area and Component Count.
Diagrams
