Product Description:
Using for fruit pastes, marzipan, soft krokant, fudge (fondant).
Design features:
— Fully automatic.
—
Top table type model.
— Suitable for small capacity.
— Stainless steel, aluminum and special ultraplastic.
— An integrated conveyor system.
— Folding cantilever type transporter.
— Accurate speed control.
Benefits:
— Compact: it takes up to 0.8 square meters.
— Forming of different shapes of product with flat bottom — bar, round, square, star etc.
— Forming without cutting — without scrap and waste
— High speed forming on the tape.
— Minimum resetting time
— Quick and easy cleaning
— Quick change of the forming set
— Custom-made forming rotor
— All parts having contact with the product are made from food-grade structural plastic and stainless steel
Working width: 200 mm .
Forming roller diameter: 200 mm .
Drive power: 1 kW
Electricity: 230/400 V, 50Hz, 3 phase
Forming speed on belt: 1 — 10 m / min
Weight: 80 kgs.
Compressed air: 5 — 6 bar
Air consumption: 2 litres / min
Dimensions:
Length: 720 mm
Width: 850 mm
The height (standard hopper): 720 mm
Forming rotor for plum and similar pastes, marzipan, soft krokant, fondant etc.
Product shape: according request — bars, rounds, squares, stars…
Length: according request
Width / Diameter: according request
Height: according request
Lubrication system for forming rotor
Capacity (maximum): up to 200 kgs / hour.
Delivery time 2 - 3 months.
